Decanter Pharmaceutical Centrifuge Machine Automatic continuous PLC Control


Working principle

Separation takes place in a horizontal cylindrical bowl equipped with a scroll conveyor. The processing material is fed into the bowl through a

stationery inlet tube and is smoothly accelerated in the accelerate chamber. Centrifugal forces cause instant sedimentation of the solids on the

wall of the bowl. The conveyor rotates in the same direction as the bowl, but at a different speed, thus moving the solids towards the conical end

of the bowl.

Descripition:

Horizontal screw centrifuge is for 0.002-3mm material for clarification, separation, dehydration, or classify 1um-5um solid phased particles. It is

wide application range, work continuously, large processing capacity, low cost, convenient maintenance and so on. It is the best equipment for

separating solid-liquid. It is widely used in chemical industry, light industry, medicine, food, paper making, mining and other industries.

Horizontal spiral centrifuge is one of our company main products. According to the requirement of the material used, we design the horizontal

spial centrifuge with one motor, two motors driving. At the same time, we design two motors separately on both sides of the machine and motors

on the same place of the machine. We also develop three column horizontal spiral centrifuge, used in the separation of coal tar oil, water, slag in

the industry, in petrochemical in the separation of oil, water, slag.

Main motor drive at full speed rotating drum, material put into spiral continuously by feed tube, evenly distributed to the spiral discharging port.

Under centrifugal force, solid content settles to the drum wall and is pushed out cone drum slag notch by the spiral pusher. Liquid is overflow

along the spiral to the drum big end. It form big end set out liquid and small end set out solid.


Tenchical parameters:
