Clarifier Oil Separator Machine 6000r/Min Speed 1200*950*1400 Size
Introduction:
Separator has many advantages, such as separation factor high,
running balance, simple operation, low oil consumption. In order to
meet
different requirements of production scale, the machine adopt
bottom washing. Facilitate liquid seal and exclusive soap, the
heart pump discharge
the material, reducing system operating pressure. Regulate
different specific gravity ring, can be suitable for all kinds of
oil, so that better
separation.
ZYDH Oil separator is the main equipment for a vegetable oil
continuous refining system, can be used for plant oil refining,
animal oil separation
, Biodiesel separation ect .continuous degreasing,
dephosphorization, de-soap, dehydration and other procedures.
Reducing the harmful
ingredients in vegetable oil, to meet national standards.
Feature:
1. Automatic discharge mode, include partly discharge and fully
discharge.
2. Applied Labyrinth seal mode, centripetal pump discharge light
liquid, with a big outlet pressure, separated light liquid can be
directly transported.
3. Centripetal pump system with stable output pressure, large
adjustment range, easy operation.
4. Power transmission applied frequency conversion start, running
smoothly, no noise and odor pollution.
5. This series disc centrifuge specially designed with safety
protection device of automatic control cabinet, all parameters can
be adjusted directly r on the touch screen, so that the separation
of discharge achieve the best effect.
6. With electric motor protection device (including automatic
start-up and normal operation).
7. Small piston with double piston structure, large amount of
discharge and more stable, low power consumption, more energy
saving.
8. Light or heavy liquid phase outlet could be adjusted by online
pressure regulating structure, clarity of light or heavy phase can
be adjusted according to end user request.
9. Panel control clear and intuitive, simple and easy operation
Application:
It can realize liquid-liquid-solid separation. it can be operated
manually or automatically or remotely. This machine is widely used
for many industries, such as dairy, beverage, pharmacy, chemials,
petrol, metallurgy and biology, etc.
This machine is widely used for many industries, such as dairy,
beverage, pharmacy, chemials, petrol, metallurgy and biology, etc.
Techincal Parameters:
| Model | Capacity (L/h) for input(coconut milk) | Basket Diameter (mm) | Rotation Rate of Drum (r/m) | Separation factor | Power (KW) | Slag discharge way | Weight (kg) | Dimension (mm*mm*mm) |
| ZYDH270 | 300 | 270 | 7200 | 6950 | 4 | automatic | 550 | 865*645*1100 |
| ZYDH315 | 500 | 315 | 6500 | 7000 | 5.5 | automatic | 650 | 900*600*1150 |
| ZYDH385 | 600 | 385 | 6500 | 7500 | 7.5 | automatic | 750 | 1100*1050*1250 |
| ZYDH430 | 800 | 430 | 6000 | 8050 | 11 | automatic | 900 | 1200*950*1400 |
| ZYDH470 | 1200-1500 | 470 | 5800 | 8500 | 18.5 | automatic | 1100 | 1250*1000*1550 |
Application :
Three phase of plant oil centrifuge:
crude oil refinery plant is the main equipment for a vegetable oil continuous refining system,
can be used for plant oil refining,continuous degreasing, dephosphorization, de-soap,
dehydration and other procedures.
Reducing the harmful ingredients in vegetable oil, to meet national
standards.
For the coconut oil/ soybean oil / palm oil, we have exported to
many countries.
Photos:
