ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification

    Buy cheap ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification from wholesalers

    Buy cheap ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification from wholesalers
    • Buy cheap ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification from wholesalers

    ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification

    Ask Lasest Price
    Brand Name : Fivemen
    Model Number : ZYDH470
    Certification : ISO
    Price : USD 8000-13000 /Set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 sets per month
    Delivery Time : 30 days after deposite
    • Product Details
    • Company Profile

    ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification

    ZYDH470 Virgin Coconut Oil Machine Stainless Steel Disc Stack ISO Certification


    Product Description:


    Zydh can separate rapid succession of solid liquid and liquid liquid ,which is a kind of vertical centrifuge.


    A rotary drum is install in the upper end of vertical shaft, the driving device driven by a motor to rotate


    at high speed. Drum have a set of a butterfly shaped parts mutually overlapped together.


    Have a very small space left between the disc and disc. Suspension pour intodrum by feeding tube


    which is located center of the drum.When the slurry flows past the clearance between the disc, solid particles in centrifuge sinking to the sediment


    is formed on the disc. Sediment falls of the disc along the sliding surface of the disc and accumulate in the drum at the largest diameter.


    The separation of the liquid exhaust drum from the liquid outlet .The function of the disc is to short


    the distance between the settlement of solid particles or liquid droplets and to expand the area of settlement of the drum.Because the installation


    disc in the drum and greatly improves the separators’ production capacity.


    Product Feature:


    1. Machine starts the friction to start off, about six to ten minutes. the machine runs smoothly, low noise and vibration, the installation path is very


    easy to operate.


    2. The bearings use imported FAG, transducer using Japan brand “ Fuji”, the main strengthen parts of Roller body and Roller cover use 2Cr13,and


    the other parts of contacted materials such as Disc all use 304L.


    3. The Stainless steel cover use SUS304


    4. The base use casting steel, coating does the same way as ship bottom.


    Product parameters:


    Model

    Capacity

    (L/h)

    Basket Diameter (mm)Rotation Rate of Drum (r/m)Separation factorPower (KW)

    Slag discharge

    way

    Weight

    (kg)

    Dimension

    (mm*mm*mm)

    ZYDH2702000270720069504automatic550865*645*1100
    ZYDH3153000315650070005.5automatic650900*600*1150
    ZYDH3854000385650075007.5automatic7501100*1050*1250
    ZYDH43050004306000805011automatic9001200*950*1400
    ZYDH47080004705800850018.5automatic11001250*1000*1550

    Application :


    Plant oil separator is the main equipment for a vegetable oil continuous refining system,can be used for plant oil refining,continuous degreasing,


    dephosphorization, de-soap,dehydration and other procedures.


    Reducing the harmful ingredients in vegetable oil, to meet national standards.


    For the coconut oil/ soybean oil / palm oil, we have exported to many countries and have the working video of the separation.


    Disc stack virgin coconut oil centrifuge machine
